Datavideo SE-2600 HD 8-ch mixer
Nagyításhoz kattintson a képre vagy használja felette az egérgörgőt!
• 8-csatornás mixer
• 4x 3G-SDI és 4x HDMI bemenet
• 3x 3G-SDI és 3x HDMI kimenet
• Felbontás: 1080p/60
• 4 USK, 2 DSK
• Audiointegráció, logó beillesztés, átmenetek
• 4x 3G-SDI és 4x HDMI bemenet
• 3x 3G-SDI és 3x HDMI kimenet
• Felbontás: 1080p/60
• 4 USK, 2 DSK
• Audiointegráció, logó beillesztés, átmenetek
• Datavideo SE-2600
• Tápegység
• Jótállás: 1 év
• Tápegység
• Jótállás: 1 év
Datavideo SE-2600 Specification |
||||
Video Standard |
Full HD |
|||
Video Format |
Input:
1080p 50/ 59.94/ 60Hz 1080i 50/ 59.94/ 60Hz 720p 50/ 59.94/ 60Hz Output: |
|||
Video Processing |
SDI: 4:2:2 HDMI: YUV 4:2:2, RGB: 4:4:4 |
|||
Input Routable / Crosspoint |
YES |
|||
Video Input |
Total 8 live inputs 4 x SDI 4 x HDMI |
|||
Mix HD & SD Source |
----- |
|||
Computer Graphic Interface |
4 via HDMI |
|||
Video Output |
3 x SDI 3 x HDMI assignable: Multiview, PGM, PVW, PGM+DSK, Clean PGM, Clean PVW, Input 1-8, STILL 1, STILL 2, Flex source |
|||
Down-converted Output |
--- |
|||
Built-in Multi-view Monitoring Out |
HDMI & SDI assignable |
|||
Analogue Audio Input |
2 x XLR/MIC (6.3mm) Combo Socket 1 x Stereo RCA set (L/R) |
|||
Analogue Audio Output |
1 x Stereo RCA set (L/R) |
|||
Digital Embedded Audio Support |
SDI Input/Output 4 channels, HDMI Input/Output 2 channels |
|||
Audio Delay Calibration |
Up to 16 fields or 8 frames per channel |
|||
A+V Switching |
Yes |
|||
Chromakey |
4 |
|||
Title Creator |
Yes |
|||
USK |
4x Keyer support Chromakey/ Linear/ Luma Key |
|||
DSK |
2x DSK support Lumakey & Linear key (Key / Fill) |
|||
Picture in Picture |
4 |
|||
Logo Insertion |
2 |
|||
Still Store |
999+ (1080p) |
|||
Effects |
Cut, Auto, WIPE, Mix, DVE, Stinger |
|||
Transition Preview |
Full transitions preview |
|||
Sync / Reference In/Out |
1 x BNC Ref in 1 x BNC Ref out (loop-through) |
|||
Tally Output |
1x D-sub 25pin, dual color |
|||
PC Remote Control |
RS-232 / DVIP (Ethernet) |
|||
Camera Control |
---- |
|||
Built-in Audio Mixer |
---- |
|||
Storage |
---- |
|||
Recording File System |
---- |
|||
Recording File Format |
---- |
|||
Video Encode |
---- |
|||
Audio Encode |
---- |
|||
Streaming Protocol |
---- |
|||
Firmware Update |
USB |
|||
Special Features |
User Memory Preset Free Virtual Set and Stinger transition included |
|||
Chassis |
Unibody |
|||
Dimension (LxWxH) |
431*313.2*84 mm |
|||
Weight |
3.8 kg |
|||
Power |
DC 12V, 82W |
|||
Operating Temp. Range |
0~40 °C |
|||
